Product Features:
◆ High Q electronic oscillator tube, the output is stable and reliable;
◆ automatic disc structure, with mechanical hands reclaimer. Improve production efficiency;
◆ easy operation, accurate positioning turntable;
◆ high-quality assembly of imported components;
◆ Single disc machining, one-person operation, saving labor.
◆ High sensitivity spark suppression circuit to prevent damage to the mold, the mold when the ignition to minimize the extent of damage, reduce product scrap rate.
Uses:
◆ Multifunctional synchronous welding machine to adapt to different thickness of the product, the use of shielded shape structure, with automatic, test mode, cutting, heating, high-cycle and other features.
Widely used in welding, cutting paper card and blister (toothbrush packaging) environmentally friendly materials (PET); synthetic leather car interiors. Dress, trademarks, strap, leather, CD bags, hot water bottle, and so on.
Products are stable, Yanbian smooth, feel good.
Technical Specifications:
Model |
XG-8000AS
|
High Frequency Power
|
8000W
380V
|
Supply Voltage
|
Input Power
|
15KVA
|
Rectifiers
|
Silicon diode
|
Oscillating tube
|
7T69RB
|
Maximum pressure
|
800KG
|
Maximum electrode spacing
|
250mm
|
Size of active horn
|
200mm
|
Fixing dimensions
|
600x800mm
Adjustable 0-10S
|
Time control
|
Operation Fang
|
Full pneumatic control
|
Dimensions
|
1200x1200x1860mm
|
Net weight
|
500KG
|
|
